RF Blind Flanges

Available materials include carbon steel, stainless steel, alloy steel, and nickel alloys across the supplied product range. Material selection should reflect the system specification, operating conditions, pressure requirements, and project documentation. Twinco can help identify an appropriate option based on the required material, application, size, pressure class, and flange-face configuration.

Rental Blind Flanges are listed in sizes from ½" to 72" and pressure classes from 125# to 2500#. The broader flange range includes sizes from ½" through 72" and ASME pressure classes 150, 300, 400, 600, 900, 1500, and 2500. Availability depends on the requested configuration and inventory.

The rental blind flange range includes Raised Face, Flat Face, RTJ, and Seal Ring Groove face options. The required face should match the mating flange, gasket or sealing arrangement, system specification, and intended application. Provide the face type with your enquiry so Twinco can help confirm compatibility and availability.

Rental Blind Flanges are offered as rental equipment, while the broader flange range supports both rental and purchase options. Rental solutions can suit hydrostatic testing, temporary isolation, maintenance shutdowns, and turnaround work where equipment is needed for a project rather than retained permanently. Purchase options support recurring or permanent piping requirements.

The Rental Blind Flanges product information states that rental studs and nuts kits are included. Confirm the required flange specification and kit contents when requesting a quote, particularly for projects involving different sizes, pressure classes, materials, or face configurations. Twinco can review the application and order requirements before preparing the equipment.

The supplied information identifies ASME B16.5 and ASME B16.47 series standards for the blind flange and flange offerings. The broader flange range also references API Standards. Confirm the applicable standard, pressure class, material, and flange dimensions against the project specification before ordering or renting.
